Product Summary

The TPSC686K016R0200 is a tantalum capacitor, which has inherently low ESR (equivalent series resistance)and is capable of higher ripple current handling, producing lower ripple voltages, less power and heat dissipation than standard product for the most efficient use of circuit power. It has been designed, manufactured, and preconditioned for optimum performance in typical power supply applications.

Parametrics

Technical specifications: (1)Capacitance Range: 0.15 μF to 1500 μF; (2)Capacitance Tolerance: ±10%; ±20%; (3)Rated Voltage (VR) ≤ +85℃: 2.5, 4, 6.3, 10, 16, 20, 25, 35, 50; (4)Category Voltage (VC) ≤ +125℃: 1.7, 2.7, 4, 7, 10, 13, 17, 23, 33; (5)Surge Voltage (VS) ≤ +85℃: 3.3, 5.2, 8, 13, 20, 26, 32, 46, 65; (6)Surge Voltage (VS) ≤ +125℃: 2.2, 3.4, 5, 8, 13, 16, 20, 28, 40; (7)Temperature Range: -55℃ to +125℃; (8)Environmental Classification: 55/125/56 (IEC 68-2); (9)Reliability: 1% per 1000 hours at 85℃, VR with 0.1Ω/V series impedance, 60% confidence level; (10)Termination Finished: Sn Plating (standard), Gold and SnPb Plating upon request Meets requirements of AEC-Q200.

Features

Features: (1)Low ESR series of robust Mn02 solid electrolyte capacitors; (2)CV range: 0.15-1500μF/ 2.5-50V; (3)14 case sizes available; (4)Power supply applications.
